AWS Infrastructure Cheat Sheet

Core Concepts and Order of Operations

1. IAM (Identity and Access Management)

First, always start with IAM because it controls access to everything else.

Basic Setup:

# 1. Create an IAM User Group
aws iam create-group --group-name Developers

# 2. Create IAM User
aws iam create-user --user-name developer1

# 3. Add user to group
aws iam add-user-to-group --user-name developer1 --group-name Developers

Common IAM Patterns:

• Always use roles for services (ECS, Lambda)
• Use groups for users
• Never put credentials in code
• Use policy conditions for extra security

Basic Developer Policy Template:

{
    "Version": "2012-10-17",
    "Statement": [
        {
            "Effect": "Allow",
            "Action": [
                "s3:List*",
                "s3:Get*",
                "s3:Put*"
            ],
            "Resource": [
                "arn:aws:s3:::my-bucket",
                "arn:aws:s3:::my-bucket/*"
            ],
            "Condition": {
                "StringEquals": {
                    "aws:RequestedRegion": "us-east-1"
                }
            }
        }
    ]
}

2. Networking (VPC and Subnets)

After IAM, set up your network infrastructure.

VPC Pattern:

• One VPC per environment (dev/staging/prod)
• Use at least two Availability Zones
• Use CIDR blocks that don't overlap

Standard VPC Setup:

# Terraform example
module "vpc" {
  source = "terraform-aws-modules/vpc/aws"

  name = "my-vpc"
  cidr = "10.0.0.0/16"

  azs             = ["us-east-1a", "us-east-1b"]
  private_subnets = ["10.0.1.0/24", "10.0.2.0/24"]
  public_subnets  = ["10.0.101.0/24", "10.0.102.0/24"]

  enable_nat_gateway = true
  single_nat_gateway = true  # Cost savings for non-prod
}

Subnet Patterns:

• Public Subnets: For ALBs, Bastions
• Private Subnets: For RDS, ECS, Lambda
• CIDR Size Guide:
  • /16 for VPC (65k addresses)
  • /24 for subnets (256 addresses)

3. Security Groups

After networking, configure security groups.

Common Patterns:

# ALB Security Group
resource "aws_security_group" "alb" {
  name        = "alb-sg"
  description = "ALB Security Group"
  vpc_id      = module.vpc.vpc_id

  ingress {
    from_port   = 443
    to_port     = 443
    protocol    = "tcp"
    cidr_blocks = ["0.0.0.0/0"]
  }
}

# ECS Security Group
resource "aws_security_group" "ecs" {
  name        = "ecs-sg"
  description = "ECS Security Group"
  vpc_id      = module.vpc.vpc_id

  ingress {
    from_port       = 8000
    to_port         = 8000
    protocol        = "tcp"
    security_groups = [aws_security_group.alb.id]
  }
}

4. Database (RDS)

After network and security, set up databases.

RDS Pattern:

resource "aws_db_instance" "main" {
  identifier        = "my-rds"
  engine            = "postgres"
  engine_version    = "13.7"
  instance_class    = "db.t3.micro"
  allocated_storage = 20

  db_name  = "myapp"
  username = "dbadmin"
  password = var.db_password

  vpc_security_group_ids = [aws_security_group.rds.id]
  db_subnet_group_name   = aws_db_subnet_group.main.name
}

5. Application Infrastructure

Finally, set up your application infrastructure.

ECS Pattern:

resource "aws_ecs_cluster" "main" {
  name = "my-cluster"
}

resource "aws_ecs_service" "main" {
  name            = "my-service"
  cluster         = aws_ecs_cluster.main.id
  task_definition = aws_ecs_task_definition.main.arn
  desired_count   = 2

  network_configuration {
    subnets         = module.vpc.private_subnets
    security_groups = [aws_security_group.ecs.id]
  }
}

Quick Reference Cheat Sheet

IAM

# Create Role
aws iam create-role --role-name MyRole --assume-role-policy-document file://trust-policy.json

# Attach Policy
aws iam attach-role-policy --role-name MyRole --policy-arn arn:aws:iam::aws:policy/AWSLambdaExecute

VPC

# List VPCs
aws ec2 describe-vpcs

# List Subnets
aws ec2 describe-subnets

# Create VPC
aws ec2 create-vpc --cidr-block 10.0.0.0/16

Security Groups

# Create Security Group
aws ec2 create-security-group --group-name MySecurityGroup --description "My security group"

# Add Rule
aws ec2 authorize-security-group-ingress --group-id sg-123456 --protocol tcp --port 80 --cidr 0.0.0.0/0

Common Problems and Solutions

1. Cannot Connect to RDS

Check:

• Security Group inbound rules
• Subnet routing
• VPC endpoint for RDS
• Database credentials

2. ECS Tasks Not Starting

Check:

• Task Role permissions
• Security Group rules
• VPC endpoint for ECR
• CloudWatch Logs permissions

3. ALB Health Checks Failing

Check:

• Security Group allows health check port
• Target Group settings
• Application responding on correct port
• Route table configuration

Best Practices

1. Naming Convention:

{environment}-{service}-{resource}
Example: prod-api-sg (Security Group for API in production)

2. Tagging Strategy:

{
  "Environment": "production",
  "Service": "api",
  "ManagedBy": "terraform",
  "CostCenter": "app1"
}

3. Security:

   • Use AWS Secrets Manager for sensitive data
   • Enable VPC Flow Logs
   • Use WAF with ALBs
   • Enable CloudTrail
   • Use GuardDuty

4. Cost Management:

   • Use AWS Cost Explorer
   • Set up Budget Alerts
   • Right-size instances
   • Use Spot Instances where possible
   • Clean up unused resources

Adding New Services Checklist

1. IAM Setup:

   • Create Service Role
   • Attach necessary policies
   • Set up cross-service permissions

2. Networking:

   • Check subnet capacity
   • Update security groups
   • Add VPC endpoints if needed

3. Security:

   • Create security group
   • Configure access policies
   • Set up encryption

4. Monitoring:

   • Set up CloudWatch logs
   • Create alarms
   • Configure metrics

5. Deployment:

   • Update CI/CD pipeline
   • Add Terraform configuration
   • Test in staging first
